The details of the scaffolding machine
| NO. | CONTENTS |
| 1 | Scaffolding plank standing tube welding device |
| 2 | Scaffolding plank ledger welding device |
3 |
Punching Device | Full automatic punching device |
| Semi-automatic punching device |
| Manual punching device |
| Spare part:punching mould |
4 |
diagonal brace flattening &punching device | Full automatic diagonal brace flattening &punching device |
| Semi automatic diagonal brace flattening &punching device |
| Manual diagonal brace flattening &punching device |
| Spare part:punching mould |
5 |
Tube cutting machine | Auto Blade cutting Device |
| Swing saw cutting device |
| Direct saw cutting device |
| Auto direct saw cutting device |
| 6 | Auto Scaffolding plank wedling line | Auto robot welding |
| Auto robot hand welding |
| 7 | Base jack & U-head jack welding device |
| 8 | Auto scaffolding plank roll forming machine |
1. Technique parameters of the processing line
(1) Plate Material: Galvanized plate/strip steel
(2) Thickness of the plate : 1.5-2mm(different thickness is ok)
(3) Machine body :350mm H steel
(3) Wall thickness of the main forming machine: 18mm steel plate
(4) Outside debugging to change sizes
(5) Transmission chain : 2’’
(7) Reducer :15kw Xingxing Cycloid which works stably and no noise.
(8) Seam type semi-mat
(9) Roller material: GCr15 with quenched treatment 62-64°C
(10) Rollers: 16 steps including 9 shafts for leveling.
(11) 4 steps side wheels on the coil-input part for avoiding coil-deviation
(12) Forming part adopts side wheel rotation forming to reduce friction between rollers and coil. Easy and fast debugging
(13) Diameter of active shaft: 80mm, 45# steel
(14) Hydraulic pump power: 7.5KW
(15) PLC control systerm with inverter
(16) Woking Speed: 8-12m/min
3,5 Main Roll Forming machine
1. Working speed :8-12 m/min
2. Material thickness :1.0-1.2mm
3. Control system:PLC
4. Decoiler :5T
5. Punching :one set
6. Main roll forming rollers:16row rollers
7. Roll material:GCR15 Steel after quenching process HRC58-62℃,he chrome plating surface treatment
8. Material of the shaft and the shaft diameter:45# steel processing, shaft diameter is 70mm
9. Main machine power :18.5kw
10. Hydraulic station power:5.5kw
11. Hydraulic pressure:24Mpa
12. Scissors punching material:Cr12Mov,Quenching HRC 58-62℃
13. Length tolerance:3m±1.0mm
14. Voltage :380V, 50HZ,3 phrase
15. driving mode :chain driving mode
16. Machine size :16.5*2.2*1.6m
17. Rolling speed:12-15m/min
18. Shaft diameter:Φ76mm
19. Material of cutting:Cr12Mov with quench HRC58-62°
20. Tolerance:10m+-0.5mm
21. Hydraulic station:5.5kw
Main Machine Parameter
| No. | Item | Unit | Data | Remark |
1 | Raw material | Type | | MSgalvanized sheet | |
| Strength of panel | Map | ≥350 | |
| Thickness of panel | mm | 1.2~2.0 | |
| 2 | Size | mm | See figure | |
| 3 | Speed | m/min | 6~8 | |
| 4 | Material of roller | | GCr15Hardening treatment | |
| 5 | Drive type | | Gear box | |
| 6 | Total power | kw | About 45 | |
| 7 | Electrical system | | PLC Inverter control | |
| 8 | Contour dimension(L*W*H) | m | 35X4X3.9 | |
